YL303H-S-12VDC
Giá: 4.700₫ Còn hàng
Category Relays Family Power, Over 2 Amps Relay
| Category | Relays |
|---|---|
| Family | Power, Over 2 Amps |
| Relay Type | General Purpose |
| Coil Type | Non Latching |
| Coil Current | 30mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 7A |
| Switching Voltage | 250VAC, 100VDC - Max |
| Turn On Voltage (Max) | 8.4 VDC |
| Turn Off Voltage (Min) | 1.2 VDC |
| Features | Sealed - Fully |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Packaging | Bulk |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Operate Time | 10ms |
| Release Time | 10ms |
| Coil Power | 360 mW |
| Coil Resistance | 400 Ohms |
| Operating Temperature | -40°C ~ 70°C |
Ứng dụng sản phẩm
