Reader NFC RDM880
Giá: 500.000₫ Còn hàng
NFC 13.56MHz Reader Module RDM880
NFC 13.56MHz Reader Module RDM880
Frequency :13.56MHz
Chips : MFRC500, MFRC400, MFRC531, MFRC632
Standard :ISO/IEC14443A, ISO/IEC14443B, ISO15693
Interface : RS232/RS485/TTL
Support card : Mf1K, Mifare 4K, Mf Ultralight, Mf Pro, AT88RF020, 66CL160S, SR176, SRIX4K(Type-B), I-Code2, TI RFID Tag-it HF-I, EM4135, EM4034 etc.
Baud Rate : 9600/115200 bps(configurable default 9600bps)
Power Supply : DC 5V(±5%)
Current : <70mA
Maximum Read Distance :Mifare: 8 cm(Tag dependent) I-Code2: 8 cm
Audio/Visual Indication : No
Antenna : External ( see HF antenna optional for RF module)
Dimension : 39mm*19mm*9mm
