MBI5168

Giá: 10.500₫ Còn hàng

8-Bit Constant Current LED Sink Driver

8-Bit Constant Current LED Sink Driver,

of Output Channel    8
Max. Sustaining Voltage    17V
Constant Output Current Per Channel    5~120mA @ 5V & 3.3V supply voltage
Max. Clock Frequency    25MHz
Output Current Accuracy-between channels    <±3% (max.)
Output Current Accuracy-between ICs    <±6% (max.)
Fast Response of Output Current, /OE (min.)    /OE (min.): 200 ns @IOUT< 60mA,/OE (min.): 400 ns @IOUT= 60~100mA
Supply Voltage    3.0~5.5V
Constant Output Current Invariant to Load Voltage Change    YES
Adjusted Output Current    through an external resistor
Schmitt Trigger Input    YES
Staggered Delay of Output    YES
RoHS Compliant Package    SOP16

   data sheet
