LED 0805 Blue

Giá: 450₫ Còn hàng

Blue 470nm LED Indication - Discrete 2.8V 0805 (2012 Metric)

Blue 470nm LED Indication - Discrete 2.8V 0805 (2012 Metric)
Color                                       Green
Wavelength - Dominant               470nm
Wavelength - Peak                       470nm
Millicandela Rating                      41mcd
Voltage - Forward (Vf) (Typ)       2.8V
Current - Test                               20mA
Viewing Angle    -
Lens Type                               Clear
Lens Style/Size    Rectangle with Flat Top, 1.4mm x 1.25mm
Package / Case                       0805 (2012 Metric)
Size / Dimension                       2.00mm L x 1.25mm W
Height                                       0.80mm
